Canon ImageRUNNER 2206N Copier




Product Details.

Compact and powerful all in one document solution

With reliable and productive printing, copy and scanning of up to 22ppm, the imageRUNNER 2206N speeds up everyday document tasks and can easily replace all other document solutions in the office, saving space and money.


Designed for optimum performance in a most demanding office environment


Enhanced device and document security allows for a complete cost-control management


Connectivity and flexibility is provided through mobile printing and scanning capabilities Machine type: Monochrome A3 Laser Multifunctional Core functions: Print, Copy, Scan and optional Send Processor/Processor speed: Canon Dual Custom Processor/400 MHZ Control Panel: 8.9 cm (3.5 inch) monochrome Touchscreen Memory: Standard: 512MB RAM

Interface Connection

100Base-TX/10Base-T Wireless LAN (IEEE 802.11 b/g/n) USB 2.0 (Device) x 1

Paper-Supply-Capacity (A4, 80gsm)

Standard: 330 sheets Paper Cassette: 250-sheet Multi-purpose tray: 80-sheet Maximum: 580 sheets (with optional Cassette Feeding Module-AD1) Paper-Output-Capacity (A4, 80gsm): 250 sheets Finishing capabilities: Collate, Rotate & Collate, Group, Rotate & Group

Supported-Media-Types (Standard)

Multi-purpose tray Plain, Recycled, Thick, Colour, Transparency, Label, Envelope, Bond, Pre-punched Cassette 1 Plain, Recycled, Colour, Pre-punched

Supported-Media-Sizes (Standard)

Multi-purpose tray: Standard size: A3, B4, A4, A4R, B5, B5R, A5, A5R, Envelope [No.10 (COM10), Monarch, DL, ISO-C5] Custom size: 95 mm x 148 mm to 297 mm x 431.8 mm Upper Cassette 1: Standard size: A3, B4, A4, A4R, B5, B5R, A5R

Supported media weights

Multi-purpose tray: 64 to 128 gsm Upper Cassette 1: 64 to 90 gsm Optional Duplex Unit: 64 to 90 gsm

Warm-up Time

From Power On: 13 Seconds or Less* From Sleep Mode: 4.3 Seconds *Time from device power on, until copy ready (not print reservation)

Dimensions (W x D x H)

622 mm x 589 mm x 499 mm (standard configuration) 622 mm x 606 mm x 600 mm (with optional DADF-AY1) 622 mm x 589 mm x 590 mm (with optional Cassette Feeding Module-AD1) 622 mm x 606 mm x 691 mm (with optional DADF-AY1 and Cassette Feeding Module-AD1)

Installation Space (W x D)

1,023 mm x 1,285 mm (with cassette and left side door open and multi-purpose tray extended)


Approx. 28.0 kg (standard configuration, toner not included) Approx. 34.8 kg (with optional DADF-AY1, toner not included)

Print Specifications

Printing method: Monochrome Laser Beam Printing Print Speed (BW): 22 ppm (A4), 11 ppm (A3), 11 ppm (A4R), 13 ppm (A5R) Print Resolution: 600 dpi x 600 dpi Page description languages: UFR II Lite/PCL 6 (Standard) Double Sided Printing: Automatic (with optional Duplex unit)

Printing from mobile and cloud

A range of software and application solutions is available to enable printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information.


PCL fonts: 45 Roman

Operating System

UFR II Lite/PCL 6: Windows 7 / Windows 8.1 / Windows 10 / Windows Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016, MAC OS X (from 10.9.5 or later) Please refer to for availability of print solutions for other operating systems and environments including AS/400, UNIX, Linux and Citrix. Some of these solutions are chargeable.

Copy Specifications

Copy Speed: 22 ppm (A4), 11 ppm (A3), 11 ppm (A4R), 13 ppm (A5R) First-Copy-Out Time (A4): Approx. 7.4 seconds or less

Copy resolution

Reading: 600 dpi x 600 dpi Printing: 600 dpi x 600 dpi Multiple Copies: Up to 999 copies Copy Exposure: Automatic or Manual (9 Levels) Magnification: 25% – 400% (1% Increments) Pre-set Reductions: 25%, 50%, 70% Pre-set Enlargements: 141%, 200%, 400%

Scan Specifications

Type Standard Flatbed (Platen) and optional Duplexing Automatic Document Feeder (DADF) Document-Feeder-Paper-Capacity DADF: 50 Sheets (A4, 80 gsm)/25 Sheets (A3, 80 gsm) Acceptable origin type, height and weight Platen: Sheet, Book, 3-Dimensional Objects (Height: up to 40 mm, Weight: up to 2kg) Document Feeder (DADF-AY1): Sheet (1-sided/2-sided continuous scanning: 52 to 105 gsm), Scanning a single original (1-sided: 37 to 128 gsm, 2-sided: 52 to 128 gsm)

Supported media sizes

Platen: Max. scanning size 297 x 431.8 mm DADF: A3, B4, A4, A4R, B5, B5R, A5, A5R, Custom size: 148 mm x 128 mm to 297 mm x 432 mm

Scan Speed (BW/CL; A4)

Single-sided: 23 ipm (300dpi)/12 ipm (300dpi) Double-sided: 8 ipm (300dpi)/4 ipm (300dpi)

Scan Resolution

BW Scan: 600 x 600 dpi CL Scan: 300 x 600 dpi

Pull Scan Specifications

MF Scan Utility can be downloaded from Canon Business Product Support Site ( Supported OS: Windows 7/8.1/10 Windows Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016 / Mac OS X (from 10.9.5 or later)

Send Specifications

Standard/Optional: Optional Destination: E-mail (SMTP), SMB Address book: Local (104 destinations)

Send resolution

BW: 300 x 300 dpi (JPEG, TIFF, PDF) CL: 200 x 200 dpi (PDF), 300 x 300 dpi (JPEG, TIFF) File Format: Standard: TIFF, JPEG, PDF, Compact PDF

Security Specifications

Authentication: Department ID management (max 100 x Department IDs)


Standard: IP/Mac Address Filtering, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP Document: Standard: Secure Print

Environmental Specifications

Operating Environment Temperature: 10 to 30 ºC (50 to 86 ºF) Humidity: 20 to 80 % RH (no condensation) Power Source: 220-240 V (±10 %), 50/60 Hz (±2 Hz), 2.7 Amp

Power Consumption

Maximum: Approx. 1.5 kW Printing: 448 W Standby: 11.3 W Sleep Mode: Approx. 2.0 W1 Plugin Off: Approx. 0.1W Typical Electricity Consumption (TEC) rating: 0.9 kWh2

Software and Printer management

Remote management tools iW Management Console: Server-based software for centralised management of a fleet of devices (includes monitoring of consumables, status monitoring and alerts, distribution of address books, configuration settings, firmware, meter capture and reporting, driver and resource management) eMaintenance: Compatible with eMaintenance services via embedded RDS (Enables meter capture, automatic consumables management, remote diagnostics and reporting for service providers to offer efficient, fast and proactive maintenance) Scanning software MF Scan Utility


Toner Cartridge/s C-EXV 42 Black Toner Toner yield (estimated yield @ 6% coverage): 10,200 pages (A4)

Paper Supply options

Optional Cassette Name: Cassette Feeding Module AD-1 Paper Capacity: 250 sheets (80 gsm) Paper Type: Plain, Recycled, Colour, Pre-punched Paper Size: A3, B4, A4, A4R, B5, B5R, A5 Paper Weight: 64 to 90 gsm Power Source: From Main Unit Dimensions (W x D x H): 580 mm x 575 mm x 117 mm Weight: Approx. 5.75 kg

Optional Duplex Unit

Enables automatic double-sided printing
